AquaJet

Van-Pack Drain Jetting Machine
The compact petrol jetter for the smallest commercial vehicles.

Navigation

By Far The Best AquaJet Ever

Operating range up to 350 mm
400 litres water tank
From 300 kg
Honda Petrol IGX800

A best-seller in our range for many years, the Rioned AquaJet combines outstanding performance with attractive pricing and low weight. Nevertheless, our engineers managed to perfect this machine further. The completely redesigned, powerful AquaJet with RioMote is by far the best AquaJet ever.

Injection Engine

Its new injection engine is more efficient and powerful than its predecessor. An additional advantage of the injection engine is that it releases less fuel vapour when in use than a carburettor engine. It is also now possible to start and stop the AquaJet remotely with the RioMote remote control that is part of the standard equipment. The electronic engine management system ensures stable engine speed under varying loads.

Strong Electric Reel

The AquaJet comes with a strong electric hosereel drive that allows the high-pressure hose to be unwound and, even under pressure, coiled. Its dimensions remain unchanged, making it suitable for almost any van. The eControl+ control panel ensures optimum ease of operation and displays information about the machine’s status in the best possible way.

Up to ø350 mm

The AquaJet is available in different capacities. Due to the stronger injection motor, the AquaJet is now available in a 200 bar / 45 lpm version, 160 bar / 55 lpm version and a high-flow machine of 140 bar / 70 lpm. Ideal for unblocking house connections but also usable in larger pipes up to 350 mm. The 60-metre-long, lightweight MaxFlow high-pressure hose has an ultra-slippery interior and a wider inner diameter for minimal pressure loss. Of course, this machine also comes with a 2-year Rioned warranty.

Specifications & documentation

Default Specifications

Operating range	Max 350 mm
Motor/drive	Honda Petrol IGX800
Fuel tank	15 liter
HP pump Rioned/Speck	200 bar / 45 lpm 160 / 55 lpm 140 bar / 70 lpm
Pump protection	Run-dry protection with overrun possibility
Pressure regulation	Type Speck with automatic bypass function
Water tank	400 litres
Filling reel	35 metres NW19
HP hose	60 metres MaxFlow
HP reel	Fixed, electrically operated (retracting and unwinding) with free-wheel
Control	eControl+ with display
Remote control	RioMote 9-channel (engine start/stop, gas regulation, HP valve control, coiling on/off HP reel, emergency stop)
Weight	From 300 kgs
Dimensions (lxwxh)	1.100 x 950 x 1.095 mm
Nozzles	1 x open, 1 x blind, ½"
Standard accessories	Spray gun with lance
Colour	Blue cover, black metal frame

Optional specifications

Riopulse pulsator	Pump adjustment to save water and increase unblocking power
Antifreeze tank	30-litre antifreeze tank with circulation capability to protect the pump in winter
Extra water tank	2 x 400 litre water tanks instead of 400 litres
Extra HP hose length	80 metres ½" HP hose instead of 60 metres
Fixed suction venturi	Surface water intake facility
Permanently attached filling hose	Fixed filling line with hydrant connection for fast tank filling
Second HP reel	Conversion of the filling reel to a second HP reel
